Glass-centered revolving doors reflect the transparent and elegant lines of modern architecture, adding a sense of spaciousness and visual continuity to entrance areas. Thanks to the natural clarity of glass, they create an uninterrupted visual transition between indoor and outdoor spaces, enhancing the architectural aesthetics of the building.
Compatible with project requirements up to 3.0 m in diameter, these systems deliver a prestigious entrance experience with their minimalist form and refined detailing.
Standard Control Panel
Touchscreen Control Panel (Optional)
Finger Protection Sensor (Standard)
Prevents fingers or hands from being trapped between the rotating wing and the fixed post.
When contact is detected, the door automatically stops.
Heel Protection Sensor (Optional)
A safety sensor that detects obstacles contacting the revolving door wing and immediately stops door movement.
Presence Sensor (Optional)
Detects people or objects located between the rotating wing and the fixed panel, stopping the door movement to ensure safety.
Light Curtain Sensor (Optional)
Mounted above the rotating wing, this sensor detects approaching people or objects and halts the rotation to prevent collisions.
Emergency Stop Button / Disabled Access Button (Standard at Entrance and Exit)
Pressing the Emergency Stop button immediately stops the door to prevent potential accidents.
The Disabled Access button reduces the rotation speed, ensuring safe and comfortable passage for users with reduced mobility.
| Standard Features | Optional Features | ||
| Technical Values | Power Supply | 115V/230V ~ 50/60 hz | – |
| Protection Class / Operating Environment | Motor IP55 / Control Panel IP22 | – | |
| Working Ambient Tempature | -40 / +60 °C | – | |
| Noise Level | Noise Level: Class A, Max. 50 dB(A) | – | |
| Security | Radar | 3 Wings Ø 1800 mm – Ø 3600 mm One unit at entrance and exit 3 Wings Ø 3601 mm – Ø 4000 mm Two units at entrance and exit | – |
| 4 Wings Ø 1800 mm – Ø 2600 mm One unit at entrance and exit 4 Wings Ø 2601 mm – Ø 4000 mm Two units at entrance and exit | – | ||
| Emergency Stop Button | One unit at entrance and exit | – | |
| Disabled Passage Button | One unit at entrance and exit | – | |
| Finger Protection Seal | Standard at entrance and exit | – | |
| Heel Sensor | – | Optional | |
| Presence Sensor | – | Optional | |
| Curtain Sensor | – | Optional | |
| Broken Wing | – | Optional | |
| Night Shield | – | Optional | |
| Electromechanical Motor Lock | – | Optional | |
| Efficiency | Air Curtain | – | Optional |
| Aluminium Mats | – | Optional | |
| Canopy Thermal Insulation | – | Optional | |
| Control System | Control Panel | Three-Position Key Switch Control Panel – Standard | |
| Touchscreen | 4 Inch Touchscreen Control Panel – Optional | ||
| Glass | Wing Glass | 4+4 Laminated Glass | – |
| Curved Glass | 4+4 Laminated Glass | – | |
| Glass Gaskets | EPDM Glass Gaskets | – | |
| Tinted Glass | – | Optional | |
| Color and Covering | Color | Standard RAL Colors and Grey Anodizing | Special RAL Colors and Special Anodizing |
| Stainless Steel Cladding | – | Satin, Polished and Mirror Stainless Steel | |
| Lighting | LED Spot 14 W | Ø 1800 mm – Ø 3400 mm Range: 4 Pieces Ø 3401 mm – Ø 4000 mm Range: 6 Pieces | Extra Spot Optional |
| Circular LED Lighting | – | Optional | |
| Hardware | Canopy | Corrosion- and Rust-Resistant, Lightweight Aluminum Profiles | – |
| Inner Ceiling | 12 Pieces 1.5 mm Thick Sliced Profil | Different Colors – Optional | |
| Roof | 1.5 mm Thick Semircircular Aluminum Sheets | Drain Channel Water Insulation | |
| Brushes | 40 mm Horsehair Brushes | – | |
| Door Handle | – | Horizontal Ø32 mm Stainless Steel Pipe, Vertical Ø40 mm Aluminum Pipe | |
| Floor Ring | – | Made of 20×40×2 mm Stainless Steel Profile | |
| Motor Heating Unit | – | Optional |
